Ultra Low Phase Noise Through Hole Package

• SC-cut crystal • High Stability • Low Aging • Ultra Low Phase Noise Option: • Standard(L)   • Premium(P)   • Ultimate(U)   -140dBc/Hz at 10 Hz; -169dBc/Hz on the floor -145dBc/Hz at 10 Hz; -170dBc/Hz on the floor -115dBc/Hz at 1 Hz -146dBc/Hz at 10 Hz; -170dBc/Hz on the floor • Sine Wave or HCMOS/TTL output • Ideal for telecommunication systems, • data communications, GPS, • instrumentation, COTS/dual use Details Contact a Representative

Follow us on LinkedIn for updates on industry news!

NEL Frequency Controls, Inc. 357 Beloit St., P.O. Box 457 • Burlington, WI 53105-0457 Phone: 262.763.3591 • Fax: 262.763.2881 • Email: sales@nelfc.com

Precision Ultra Low Phase Noise OCXO

Precision High Stability Low Profile 22 x 25 x 10 mm SMD Package Specifications  SC-cut crystal  High stability  Low Profile SMD package  Ultra Low Phase Noise at •  10MHz Output Frequency •  -100 dBc/Hz at 1 Hz •  -135 dBc/Hz at 10 Hz •  -153 dBc/Hz at 100 Hz •  -162 dBc/Hz at 1 KHz •  -165 dBc/Hz at 10 KHz •  -168 dBc/Hz at 100 KHz  TTL output  Ideal for instrumentation, •  telecommunications and GPS Details Contact a representative
